Product Summary
The AM79C961AKC is a single-chip Ethernet controller. It is a highly integrated system solution for the PC-AT Industry Standard Architecture (ISA) architecture. The AM79C961AKC is designed to provide flexibility and compatibility with any existing PC application. This highly integrated 132-pin VLSI device is specifically designed to reduce parts count and cost, and addresses applications where higher system throughput is desired. The AM79C961AKC is fabricated with AMD’s advanced low-power CMOS process to provide low standby current for power sensitive applications.
Parametrics
AM79C961AKC absolute maximum ratings: (1)Storage Temperature: –65 to +150℃; (2)Ambient Temperature: 0 to +70℃; (3)Supply Voltage to AVss or DVSS (AVDD, DVDD): –0.3 V to +6.0 V.
Features
AM79C961AKC features: (1)Single-chip Ethernet controller for the Industry Standard Architecture (ISA) and Extended Industry Standard Architecture (EISA) buses; (2)Supports IEEE 802.3/ANSI 8802-3 and Ethernet standards; (3)Supports full duplex operation on the 10BASE-T, AUI, and GPSI ports; (4)Direct interface to the ISA or EISA bus; (5)Pin compatible to Am79C961 PCnet-ISA+ Jumperless Single-Chip Ethernet Controller; (6)Software compatible with AMD’s Am7990 LANCE register and descriptor architecture; (7)Low power, CMOS design with sleep mode allows reduced power consumption for critical battery powered applications; (8)Supports 8 interrupts on chip; (9)Look Ahead Packet Processing (LAPP) allows protocol analysis to begin before end of receive frame; (10)Supports 4 DMA channels on chip; (11)Supports 16 I/O locations; (12)Supports 16 boot PROM locations.
Diagrams
 |
